Wet Scrubbers

Impinjet® Wet Scrubbers

Impinjet-imgSly Impinjet wet scrubbers clean, cool and absorb vapors and gases from incoming airstreams, as well as collect particulates. High collection efficiencies (99% @5 microns) are achieved with low water consumption and minimum pressure drop. Capacities to 200,000+ CFM. Highly resistant to fouling, the Impinjet Wet Scrubber is the ideal scrubber for applications requiring both condensing and particulate removal. Constructed in either metal or plastic, each scrubber stage acts as a discrete fractional collector. Often referred to as “plate scrubbers or tray scrubbers”, the Impinjet units are available in multiple stage designs to maximize efficiencies.

Venturi Wet Scrubbers

VenturiThe Sly Venturi Scrubber efficiently collects fine particulate and mists. Scrubbing liquid is atomized into fine droplets. Adjustable throats for performance optimization are standard. Capacities to 76,000+ CFM per unit.

Designs are available for high temperature, highly corrosive applications. Venturis can be coupled with Impinjet scrubbers to achieve maximum efficiencies.

Eductor Wet Scrubbers

Eductor Wet ScrubbersEductor scrubbers are designed to remove soluble gases and particulate by inducing a gas flow using high pressure liquid focused into a venturi throat. Additionally, eductor scrubbers can be used for direct-contact condensation. A high liquid flow rate makes the Sly eductor particularly appropriate for collection of sticky and/or gummy particulate, as well as gases which decompose upon contact with water, such as SiCl4 and H2SiF6.

Packed Tower

Packed TowerPacked tower scrubbers (also referred to as packed bed or packed column scrubbers) are designed for chemical scrubbing of contaminants from gas streams. Internal packing in the scrubber housing provides a large wetted surface area to induce intimate contact between the contaminated gas and the scrubbing liquid.

About Environmental Solutions

Since 1995, Environmental Solutions has been helping businesses, like yours, improve their workplace efficiency and air quality. We represent a number of best in class brands, including Donaldson Torit, Schubert, Nilfisk, Worldwide Electric Corp., and others. We offer fast, expert service at highly competitive prices and would welcome the opportunity to earn your business.

CALL TOLL FREE 1-866-438-7891
